Description
Compact data storage for edge deployments
Consolidate and safeguard
Protect all your data with integrated security features and centralized access.
Manage important data
Share, back up, and access files, photos, surveillance video, and more.
Minimize energy impact
15 watts under full operation keeps operating costs low.
Simply faster
DS224+ is faster at indexing files in Synology Drive and Synology Photos and more capable of running demanding web applications compared to previous-generation systems.1
Store, share, and protect
Manage all your documents, images, and other files, back up applications and devices, and protect your property with professional video surveillance.
Private cloud for data sharing
Hybrid work in the private cloud
Store, sync, access, and share data from any device, wherever you are. Work together seamlessly across different platforms, accessing files through mobile apps, desktop clients, or a browser-based interface. Quickly and easily roll back files in case of unwanted deletion or modification thanks to smart versioning.
Multi-layered backup
Back up workstations, smartphones, cloud apps, and more
Consolidate and automate backup tasks for workstations, file servers, VMs, SaaS applications, and more with Active Backup Suite. Administer device backups remotely through a centralized portal and quickly restore specific files or entire devices to keep your business up and running. Take advantage of built-in remote backup solutions designed to protect your data with seamless 3-2-1 backup configurations.
Smart surveillance management
Synology Surveillance Station
Protecting your business has never been easier, with centralized management, support for over 8,300 IP camera models, and remote monitoring and playback. Synology’s video management system provides all the tools you need for live monitoring, investigation, management, and backup.3
Btrfs: advanced file system for data protection
The Synology DiskStation Manager (DSM) operating system that powers the DS224+ uses the advanced Btrfs file system, which safeguards your data against corruption and allows for the reversal of unintended or malicious changes through the use of snapshot technology.
Performance backed by Synology drives
Leverage high sustained performance and reliability with well-engineered drives designed specially for Synology systems.4
Specifications
| Storage | |
|---|---|
| Storage drives installed | No |
| Installed storage drive type | No |
| Supported storage drive types | HDD & SSD |
| Number of storage drives supported | 2 |
| Storage drive interface | Serial ATA |
| Storage drive size | 2.5/3.5″ |
| RAID support | Yes |
| Supported file systems | BTRFS, Fat, HFS+, NTFS, exFAT, ext3, ext4 |
| RAID levels | 0, 1, JBOD |
| Processor | |
| Processor manufacturer | Intel |
| Processor boost frequency | 2.7 GHz |
| CPU configuration (max) | 1 |
| Processor frequency | 2 GHz |
| Processor family | Intel® Celeron® |
| Processor model | J4125 |
| Processor cores | 4 |
| Memory | |
| Internal memory type | DDR4 |
| Internal memory | 2 GB |
| Maximum RAM supported | 6 GB |
| Network | |
| Ethernet LAN | Yes |
| Wake-on-LAN ready | Yes |
| Supported network protocols | SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS Kerberized sessions, iSCSI, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV |
| iSCSI support | Yes |
| Ports & interfaces | |
| USB port | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| Ethernet LAN (RJ-45) ports | 2 |
| Hard drive | |
| RAID support | Yes |
| Supported file systems | BTRFS, Fat, HFS+, NTFS, exFAT, ext3, ext4 |
| RAID levels | 0, 1, JBOD |
| Design | |
| Cooling type | Active |
| Fan diameter | 9.2 cm |
| Product colour | Black |
| Number of fans | 1 fan(s) |
| LED indicators | Yes |
| Chassis type | Desktop |
| Technical details | |
| Type | NAS |
| Device class | Home & Home Office |
| Backup function | Yes |
| Product colour | Black |
| Number of users | 1200 user(s) |
| Noise level | 22 dB |
| LED indicators | Yes |
| Chassis type | Desktop |
| Number of fans | 1 fan(s) |
| Performance | |
| Browser supported | Google Chrome, Firefox, Microsoft Edge, Safari |
| Type | NAS |
| Device class | Home & Home Office |
| Backup function | Yes |
| On/off switch | Yes |
| Number of users | 1200 user(s) |
| Noise level | 22 dB |
| Access Control List (ACL) | Yes |
| USB copy function | Yes |
| Cooling | |
| Cooling type | Active |
| Fan diameter | 9.2 cm |
| Number of fans | 1 fan(s) |
| Security | |
| Access Control List (ACL) | Yes |
| Management features | |
| On/off switch | Yes |
| Power | |
| Power supply unit (PSU) capacity | 60 W |
| AC input voltage | 100 – 240 V |
| AC input frequency | 50 – 60 Hz |
| External power adapter | Yes |
| Weight & dimensions | |
| Width | 108 mm |
| Depth | 232.2 mm |
| Height | 165 mm |
| Weight | 1.3 kg |
| Packaging content | |
| External power adapter | Yes |
| Cables included | AC, LAN (RJ-45) |
| Operational conditions | |
| Storage temperature (T-T) | -20 – 60 °C |
| Operating temperature (T-T) | 0 – 40 °C |
| Operating relative humidity (H-H) | 5 – 95% |
| Packaging data | |
| Cables included | AC, LAN (RJ-45) |
